01
What you have
Aging or unreliable documentation
Paper drawings, scanned PDFs, obsolete files, incomplete dimensions, or a physical part with no usable model.
Engineering data modernization
Turn legacy drawings into production-ready CAD.
We transform aging prints, scanned drawings, obsolete CAD files, and undocumented parts into accurate 3D models and modern engineering documentation.
NDA-ready workflow
Manufacturing-minded
U.S.-based service
Source
Legacy drawing
Output
Verified CAD
ASSEMBLY BRACKET
DWG 1028-A
ARCHIVE COPY
Model validated
From archive to advantage
More than a redraw. A usable engineering asset.
Every project is built around the way your team will actually manufacture, inspect, revise, and reuse the data.
02
What we create
Accurate, editable CAD
Native parametric models, updated drawings, neutral files, and clear documentation of every discrepancy or assumption.
03
What you receive
Organized data your team can trust
A structured project package prepared for production, quoting, inspection, revisions, and future system migration.
Core capabilities
Built around the real problems inside legacy engineering data.
01
Drawing-to-CAD conversion
Parametric 3D models and modern drawings created from paper, PDF, TIFF, DWG, DXF, or customer-supplied data.
- Native editable models
- STEP and Parasolid exports
- Updated 2D documentation
02
Validation and cleanup
Conflicts and uncertainties are identified instead of silently becoming part of the new model.
- Missing-dimension review
- Tolerance and GD&T checks
- Assumptions reporting
03
Legacy CAD modernization
Entire engineering archives can be standardized and prepared for controlled use across your organization.
- Templates and properties
- File and revision standards
- PDM, PLM, and MES preparation
04
Reverse-engineering support
Build usable documentation from physical components, measurements, inspection reports, or scan data.
- Physical-part reconstruction
- CMM and scan-data support
- Replacement-part documentation
The business case
Preserve the knowledge. Remove the uncertainty.
Legacy drawings are more than old files. They contain product knowledge, manufacturing decisions, and decades of company history. When that information is inaccessible, unclear, or dependent on one experienced employee, it becomes a business risk.
Explore our servicesReduce risk
Identify missing, conflicting, or uncertain information before it reaches production.
Save engineering time
Stop repeatedly interpreting or rebuilding the same information from old documents.
Improve quality
Create consistent models and drawings that support better inspection and fewer revisions.
Protect continuity
Keep critical product knowledge available after retirements, acquisitions, or supplier changes.
A clear process
Start small. Prove the value.
Begin with one representative drawing or a small pilot package before committing to a larger archive-modernization project.
Send one representative file
Provide a drawing, PDF, obsolete CAD file, inspection data, or photographs of the physical component.
Review
Receive a defined pilot quote
We review complexity, deliverables, assumptions, and turnaround before any work begins.
Scope
We recreate and validate
The model and documentation are created, checked, and compared against the available source information.
Build
Receive an organized CAD package
Files are delivered in agreed formats with assumptions, discrepancies, and revision information clearly stated.
Deliver
Start with one drawing
See what your legacy engineering data can become.
Send us one representative file for a no-obligation project review and pilot quote.
Request a pilot quote NDA available before files are shared.
